Round Diffuser |
||||||
|
Model RF and RS supply diffusers are
recommended for heating , Ventilating and cooling and are equipped with
fully flush or stepped down cores for maximum range of performance. High diffusion induction rates result in rapid temperature and velocity equalization of the mixed air mass well above the zone occupancy. FEATURES AND BENEFITS Fixed air pattern with stepped down and flush cone. Horizontal air pattern of 360 o with maximum performance range. Removable centre cone affords access to accessories. All necessary adjustments are easily made without disturbing the ceiling or removing the diffuser. Diffuser are equipped with margins designed to minimize smudging. minimum dirt development on ceiling in normal application. Duct rings for mounting finished as standard. Diffuser outer shell fastens directly to duct ring with concealed fastens directly to duct ring with concealed fasteners; margins fit tight to ceiling for optimum ceiling appearance. Cost savings result from less installation time. Diffusers and accessories are constructed of steel and aluminium. FINISHED Extruded Aluminium Construction Natural anodized or baked enamel in white as a standard, special anodize or baked enamel in various colour are also available on request. Steel Construction White baked enamel as a standard finish, special colour finishes are also available to match architectural requirement. Accessories Buttery Damper for round necks. The dampers manufactured from sheet steel, standard finish is baked enamel in black matt colour. Sliding blade damper for round necks. The dampers manufactured from sheet steel standard finish is baked enamel in black matt colour. |
||||||
| Flush Face Standard Size Table | Stepped Down Face Standard Size table | |||||
 |
 |
|||||
|
||||||
